| 1/2.8" 5MP IMX568 global shutter CMOS sensor |
|
Supports H.265+, H.265, and H.264 encoding |
|
Supports mirror and flip, backlight compensation, strong light suppression, 3D digital noise reduction, fog penetration, and digital wide dynamic range |
|
Support 8pcs IR led for Black&white vision |
|
Supports standard ONVIF, HIKVISION, Dahua NVR Supports POE / DC12V power adapter Supports AIISP image enhancement and enhances low noise effect |
|
Specifications |
|
|
Master chip |
Hi3516DV500, ARM Cortex A55@850MHz dual-core |
|
DDR（ internal storage ） |
8GB LP DDR4 |
|
Flash |
1GB SPl Nor Flash (2GB optional) |
|
imaging sensor |
5MP 1/2.8 IMX568 global shutter low-light CMOS sensor, color: 0.001Lux@F1.2, black and white: 0.001Lux@F1.2 |
|
Fixed lens |
3.6mm(default), 2.8mm optional |
|
Wide Dynamic |
120 dB |
|
Master stream frame rate resolution |
30 fps@（2592 ×1944，2560 ×1440） |
|
Subcode stream frame rate resolution |
30 fps@（704×576，640×480） |
|
Three stream frame rate resolution |
30 fps@（704×576，640×480，640*352，320*240） |
|
Frame rate enhancement |
It supports up to 1080P@50FPS |
|
Video compression standard |
H.265+/H.265/H.264 |
|
Video compression bit rate |
512 Kbps~32 Mbps |
|
white balance |
Auto/manual/one white balance |
|
shutter |
1/12 second to 1/100,000 second |
|
denoise |
3D/2D noise reduction |
|
Wide Dynamic |
Support digital wide dynamic |
|
automatic diaphragm |
Supports DC IRIS and automatic aperture |
|
AIISP |
Supports AISP image enhancement |
|
Image function |
Support backlight compensation, strong light suppression, fog penetration, anti-flicker, lens correction, mirror, flip, gain and other functions |
|
Network |
1 RJ45 Ethernet port, 100 M/1000 M adaptive |
|
WiFi |
2.4G Hz / 5G Hz(optional) |
|
IR led |
8pcs IR led |
|
Audio output |
Internal speaker |
|
Reset button |
External |
|
Casing shape |
Vandalproof Bullet Casing |
|
weight of camera |
500 g |
|
Working temperature |
-20℃～+60℃ |
|
Power supply and power consumption |
POE/DC12V power adapter, 5W power consumption |
