Technical specs |
||
|
camera |
||
|
master chip |
Hi3519DV500, ARM Cortex A55@1000MHz dual-core |
|
|
DDR |
1GB DDR4 |
|
|
Flash |
128MB SPI NAND Flash |
|
|
imaging sensor |
8MP 1/1.8 IMX678 CMOS sensor for low-light conditions, with a color sensitivity of 0.0001Lux@F1.0 and a black-and-white sensitivity of 0.0001Lux@F1.0 |
|
|
watchdog |
hardware watchdog |
|
|
Wide Dynamic |
120 dB |
|
|
iris diaphragm |
F1.4~F5.0 |
|
|
convergence control |
voluntarily |
|
|
Motorized optical zoom Lens |
5.9-94.4mm±5% |
|
|
angle of view |
wide angle |
65.3° x 38.4° |
|
|
far point |
1.7° x 1.0° |
|
image parameter |
||
|
primary stream frame rate resolution |
30 fps@（3840 × 2160，2880 × 1620，2560× 1440，1920× 1080） |
|
|
sub-stream frame rate resolution |
30 fps@（1280×720，704×576，640×480） |
|
|
three code stream frame rate resolution |
30 fps@（704×576，640×480） |
|
|
video compression standard |
H.265+/H.265/H.264/MJPEG |
|
|
video compression bitrate |
512 Kbps~32 Mbps |
|
|
Character & Watermark Overlay |
support |
|
|
electronic shutter |
1/12 second to 1/100,000 second |
|
|
denoise |
Supports 3D/2D noise reduction |
|
|
Wide Dynamic |
Supports digital wide dynamic range |
|
|
AIISP |
Supports AISP image enhancement |
|
|
Image Features |
Supports backlight compensation, bright light suppression, fog penetration, anti-glare, lens correction, mirror image, flip, gain, and other functions. |
|
|
network connections |
||
|
Preview route count |
Up to 12 channels |
|
|
networking protocol |
Supports network protocols including CGI, HTTP, HTTPS, GB28181, SIP, RTMP, TCP/IP, UDP, RTP, FTP, RTCP, RTSP, NTP, DHCP, DNS, DDNS, SNMP, SSL/TLS, and WebSocke, as well as standard protocols like ONVIF. |
|
|
Auxiliary interface |
||
|
network |
1 RJ45 Ethernet port, 100 M/1000 M adaptive |
|
|
audio frequency |
1 input: Supports microphone or speaker input; 1 output: Supports connecting headphones or amplifier |
|
|
General parameters |
||
|
product size |
85.5×50×60mm (L×W×H) |
|
|
weight of equipment |
400g |
|
|
working temperature |
-30℃ ~ +60℃; 20%~80%RH |
|
|
Power Supply and Power Consumption |
DC: 9V~12V,5W (MAX) power consumption |
|
