| Item | Item | Detail |
|
Algorithm | Snap Rate | ≥99.9% |
| Recognize Rate | ≥99.9%（Typical Scene + Typical License Plate） | |
| Car speeds | 0-80KM/h | |
| Plate type | Over 130 country and region | |
| Target features | Number\Color\Type\Size | |
| License plate anti-counterfe iting | Abnormal license plate (mobile phone photo and printing) alarm is supported | |
| Unlicensed vehicles | Support unlicensed vehicles | |
| License plate whitelist | Support accurate and intelligent fuzzy matching of whitelist license plate rules | |
| Smart calibration | Supports smart calibration of license plate number and license plate type and color accurately or in the form of wildcards | |
| Image | Basic configuration | Built-in intelligent ISP algorithm, intelligent optimization and dimming, intelligent adaptation to complex scenes |
|
Video/Audio | Video compression standards |
H.264/H.265/MJPEG; |
| Resolution | 640*360、704*576、1280*720、1920*1080、2048*1536、2560*1440、 2880*1620 | |
| Video Bitrate | 512Kbps~5000Kbps | |
| Frame rate | 1~25FPS | |
| Audio coding | G.711/AAC； | |
| Protocols | Protocols | SDK、ONVIF、HTTP、RTSP、TCP/IP、UDP、RS485、IO、NTP、 |
|
| VPN、FTP、UPNP | |
|
Networking | local networking | No need for a host computer or server, automatic operational networking between cameras |
| Parking lot management | Supports the creation of multiple parking lots and scenario management of multiple cameras | |
| Black and white lists | Work with strategy to meet vehicle hierarchy management | |
| complementa ry camera | Up to 4 auxiliary cameras can be added to the same exit/entry point | |
| LED Output | Support external LED screen display, output recognition\billing results | |
| Audio Output | External speakers can be used to broadcast the identification and billing results | |
|
Item |
Item |
Detail |
|
Algorithm |
Snap Rate |
≥99.9% |
|
Recognize Rate |
≥99.9%（Typical Scene + Typical License Plate） |
|
|
Car speeds |
0-80KM/h |
|
|
Plate type |
Over 130 country and region |
|
|
Target features |
Number\Color\Type\Size |
|
|
License plate anti-counterfeiting |
Abnormal license plate (mobile phone photo and printing) alarm is supported |
|
|
Unlicensed vehicles |
Support unlicensed vehicles |
|
|
License plate whitelist |
Support accurate and intelligent fuzzy matching of whitelist license plate rules |
|
|
Smart calibration |
Supports smart calibration of license plate number and license plate type and color accurately or in the form of wildcards |
|
|
Image |
Basic configuration |
Built-in intelligent ISP algorithm, intelligent optimization and dimming, intelligent adaptation to complex scenes |
|
Video/Audio |
Video compression standards |
H.264/H.265/MJPEG; |
|
Resolution |
640*360、704*576、1280*720、1920*1080、2048*1536、2560*1440、2880*1620 |
|
|
Video Bitrate |
512Kbps~5000Kbps |
|
|
Frame rate |
1~25FPS |
|
|
Audio coding |
G.711/AAC； |
|
|
Protocols |
Protocols |
SDK、ONVIF、HTTP、RTSP、TCP/IP、UDP、RS485、IO、NTP、VPN、FTP、UPNP |
|
Networking |
local networking |
No need for a host computer or server, automatic operational networking between cameras |
|
Parking lot management |
Supports the creation of multiple parking lots and scenario management of multiple cameras |
|
|
Black and white lists |
Work with strategy to meet vehicle hierarchy management |
|
|
complementary camera |
Up to 4 auxiliary cameras can be added to the same exit/entry point |
|
|
LED Output |
Support external LED screen display, output recognition\billing results |
|
|
Audio Output |
External speakers can be used to broadcast the identification and billing results |
|
|
|
||
|
Cate |
Item |
Integrated |
Module |
|
Image |
Sensor |
5MP |
|
|
Resolution |
2880(H) x 1620(V) |
||
|
Low light |
0.1LUX color（with fill light） |
||
|
electronic shutter |
0-1ms or customized |
||
|
Lens |
6mm Fixed Lens |
||
|
Optional 2.8~12mm、7~22mm、5~50mm Lens |
|||
|
Lens interface |
M12 |
||
|
Image parameters |
Image configuration |
Brightness, contrast, saturation, image flip, exposure time, etc. |
|
|
Noise reduction |
Support 2D/3D noise reduction |
||
|
WDR |
Support |
||
|
Ports/Button |
Network |
1 * 10/1000Mbps Adaptive RJ45 port |
|
|
1 * 10/100Mbps Adaptive RJ45 port |
|||
|
IO Input |
4 channels |
||
|
RS485 |
2 channels |
||
|
TF-card |
1 TF card slot, supports up to 256G capacity |
||
|
Bluetooth |
Support |
||
|
LCD driver |
Optional |
||
|
Voice intercom |
Optional |
||
|
Reset |
1* RESET Button |
||
|
Status light |
Support |
||
|
Storage |
Storage |
32G |
|
|
Reliability parameters |
temperature |
operating temperature：-30℃~70℃ |
|
|
Power supply |
12V DC 2A for basic configurations (without speakers, screens and other high power consuming components) |
||
|
12V DC 5A for extended configurations (with speakers, screens and other high-power components) |
|||
|
power consumption |
Power consumption ≤ 8W (basic set, including fill light, excluding speakers, screen and other high power consumption components) |
||
|
Power consumption ≤ 55W (extended set with speakers, screen and other high power consumption components) |
|||
|
Protection |
IP65 |
-- |
|
|
Structural parameters |
Dimensions |
440mm（L）*144mm(W)*103mm(H) |
109mm（L）*149mm(W)*72mm(H) |
